A-9
Cisco 7600 Series Router Installation Guide
OL-4503-26
Appendix A Technical Specifications
Cisco 7600 Series Router Power Supplies
Cisco 7600 Series Router Power Supplies
Table A-9 lists the specifications for the Cisco 7600 series router power supplies.
Airflow
WS-C6K-13SLT-FAN2 (Optional high-speed fan
tray)—1090 CFM
Acoustical Noise
61.4 to 77 dB. International Organization for
Standardization (ISO) 7779: Bystander position
operating to an ambient temperature of 86°F (30°C).
1. Designed and tested for normal operation for altitudes up to 10000 ft (3048m); safety approvals apply only to an operating
altitude of 6500 feet (2000 m).
2. RU = rack units
Table A-8 Cisco 7613 Router Specifications (continued)
Item Specification
Ta b l e A-9 Power Supply Specifications
Item Specification
950 W AC- and DC-input Power Supplies
AC-input type Autoranging input with power factor corrector
AC-input voltage rating 100 to 240 VAC (±10% for full range)
AC-input current rating 12-5 A
AC-input frequency 50/60 Hz (nominal)
Power supply output capacity 950 W maximum (100–240 VAC )
DC-input voltage rating -48 VDC to -60 VDC continuous
DC-input current rating 25 A
Power supply output (AC supply) +1.5V @ 15A, +3.3V @ 2.5A, +50V @ 19.15A
Power supply output (DC supply) +1.5V @ 15A, +3.3V @ 2.5A, +50V @ 19.15A
Output holdup time 20 ms minimum (AC-input power supply)
4 ms (DC-input power supply)
1400 W AC-input Power Supplies
Specification
AC-input type Autoranging input with power factor corrector
AC-input voltage rating 100 to 240 VAC (±10% for full range)
AC-input current rating • 16 A @ 100 VAC
• 8 A @ 240 VAC
AC-input frequency 50/60 Hz (nominal) (±3 Hz for full range)
Power supply output capacity 1400 W
Power supply output • 15.0 A @ 1.5V
• 2.5A @ 3.3V
• 27.4 A @ 50V
