3-29
Cisco 7600 Series Router Installation Guide
OL-4503-26
Chapter 3 Installing the Cisco 7600 Series Router
Attaching the Interface Cables
Figure 3-28 SC-Type Fiber-Optic Connector
Figure 3-29 LC Fiber-Optic Connector
Figure 3-30 MT-RJ Fiber-Optic Connector
Figure 3-31 Mini-SMB Cable Connector
Figure 3-32 RJ-45 Connectors
247372
58476
14367
77891
48129
