A-11
Cisco 7600 Series Router Installation Guide
OL-4503-26
Appendix A Technical Specifications
Cisco 7600 Series Router Power Supplies
1900 W AC- and DC-input Power Supply
AC-input type Autoranging input with power factor corrector
AC-input voltage rating 100 to 240 VAC (±10% for full range)
AC-input current rating 12A
AC-input frequency 50/60 Hz (nominal)
Power supply output capacity 1050 W maximum (100–120 VA C )
1900 W maximum (200–240 VA C )
DC-input voltage rating -48 VDC to -60 VDC continuous
DC-input current rating 50A
Power supply output (AC supply) +1.5V @ 15A, +3.3V @ 2.5A, +50V @ 20.38A (110 VAC)
+1.5V @ 15A, +3.3V @ 2.5A, +50V @ 37.38A (220 VAC)
Power supply output (DC supply) +1.5V @ 15A, +3.3V @ 2.5A, +50V @ 37.38A
Output holdup time 20 ms minimum (AC-input power supply)
8 ms (DC-input power supply)
2500 W DC-input Power Supply Specification
Power supply output capacity 2500 W maximum.
System power dissipation 3520 W (total input power).
DC-input voltage rating -48 VDC to -60 VDC continuous.
DC-input current 80A
Power supply output rating 15A @ +3.3V, 5A @ +5V, 12A @ +12V, 55.5A @ +42V.
DC input terminal block Accepts 2-14 AWG copper conductors. Actual size of the
wire needed is determined by the installer or local
electrician. Terminal block material rated at 150°C.
Output holdup time 4 ms
2700 W AC-input Power Supply Specification
AC-input type Autoranging input with power factor corrector
AC-input voltage rating 100 to 120 VAC, 200 to 240 VAC (±10% for full range)
AC-input current rating • 16 A @ 200 VAC (2700 W output)
• 16 A @ 100 VAC (1350 W output)
Power supply output capacity • 1350 W maximum (100–120 VAC)
• 2700 W maximum (200–240 VAC)
AC-input frequency 50/60 Hz (nominal) (±3% for full range)
Power supply output • +1.5V @ 15A, +3.3V @ 2.5A, +50V @ 27.49A (110
VAC )
• +1.5V @ 15A, +3.3V @ 2.5A, +50V @ 55.61A (220
VAC )
KVA rating 3.4 KVA (high-line operation)
Table A-9 Power Supply Specifications (continued)
Item Specification
