D-1
Cisco 7600 Series Router Installation Guide
OL-4503-26
APPENDIX
D
Repacking the Cisco 7600 Series Router
This appendix provides repacking and shipping instructions for the following routers if you need to
return your switch to the factory:
• Cisco 7603 Router, page D-1
• Cisco 7606 Router, page D-2
• Cisco 7609 Router and Cisco 7609-S Router, page D-4
• Cisco 7613 Router, page D-6
Cisco 7603 Router
Warning
To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the
handles on modules (such as power supplies, fans, or cards); these types of handles are not designed
to support the weight of the unit. Lift the unit only by using handles that are an integral part of the
chassis, or by grasping the chassis underneath its lower edge.
If you need to return or move the Cisco 7603 Router, follow these steps to repack the switch using the
original packaging material:
Step 1 Set the chassis on the packing material on the bottom pallet. (See Figure D-1.)
Step 2 Place the packing material on the sides of the chassis.
Step 3 Place the top packing material over the top of the switch.
Step 4 Place the accessory kit on the top packing material.
Step 5 Place the shipping carton so the open end is on one side and the glue joint is at the top; slide the pallet
into the carton horizontally.
Step 6 Seal the carton with packing tape.
