2-13
Cisco 7600 Series Router Installation Guide
OL-4503-26
Chapter 2 Preparing for Installation
Site Requirements
Table 2-11 lists the power and the heat numbers for the Fast Ethernet switching modules.
WS-X6148A-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
2.68 112.56 140.70 480.49 151.29 516.66
WS-X6516-GE-TX
16-port 10/100/1000 Ethernet
module
3.45 144.90 181.13 618.54 194.76 665.10
WS-X6548-GE-TX
48-port 10/100/1000 Ethernet
module
2.98 125.16 156.45 534.28 168.23 574.49
WS-X6548V-GE-TX
10/100/1000 Ethernet module
with WS-F6K-VPWR-GE PoE
daughter card
3.40 142.80 178.50 609.58 191.94 655.46
WS-X6548-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
3.16 132.72 165.90 566.55 178.39 609.19
WS-X6748-GE-TX
10/100/1000 Ethernet module
7.00 294.00 367.50 1255.01 395.16 1349.48
Table 2-10 Power Requirements and Heat Dissipation—10/100/1000 Ethernet Switching Modules (continued)
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
Ta b l e 2-11 Power Requirements and Heat Dissipation—Fast Ethernet Switching Modules
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-X6148-FE-SFP
48-port 100BASE-X module
2.3 96.60 120.75 412.36 129.84 443.40
WS-X6224-100FX-MT
24-port 100BASE-FX Ethernet
module, MMF
1.90 79.8 99.75 340.65 107.26 366.3
WS-X6324-100FX-MM
24-port 100BASE-FX Ethernet
module, MMF
1.52 63.84 79.8 272.52 85.81 293.03
