2-15
Cisco 7600 Series Router Installation Guide
OL-4503-26
Chapter 2 Preparing for Installation
Site Requirements
Table 2-13 lists the power and the heat numbers for the 10BASE Ethernet switching modules.
Table 2-14 lists the power and the heat numbers for the FlexWAN and the enhanced FlexWAN modules.
WS-X6148X2-45AF
96-port 10/100 Ethernet module
with WS-F6K-FE48X2-AF PoE
daughter card
3.07 128.94 161.18 550.41 173.31 591.84
WS-X6196-RJ-21
96-port 10/100 Ethernet module
2.74 115.08 143.85 491.25 154.68 528.22
WS-X6196-21AF
96-port 10/100 Ethernet module
with WS-F6K-FE48X2-AF PoE
daughter card
3.16 132.72 165.90 566.55 178.39 609.19
WS-X6248A-TEL
48-port 10/100 Ethernet module
(telco)
2.69 113 141.23 482.28 151.85 518.58
WS-X6348-RJ21V
48-port 10/100 Ethernet module
with WS-F6K-VPWR PoE
daughter card
2.39 100.38 125.48 428.5 134.92 460.75
WS-X6348-RJ-45
48-port 10/100 Ethernet module
2.39 100.38 125.48 428.5 134.92 460.75
WS-X6348-RJ-45V
48-port 10/100 Ethernet module
with WS-F6K-VPWR PoE
daughter card
2.39 100.38 125.48 428.5 134.92 460.75
WS-X6548-RJ-21
48-port 10/100 Ethernet module
2.90 121.80 152.25 519.93 163.71 559.07
WS-X6548-RJ-45
48-port 10/100 Ethernet module
2.90 121.80 152.25 519.93 163.71 559.07
Table 2-12 Power Requirements and Heat Dissipation—10/100 Ethernet Switching Modules (continued)
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
Ta b l e 2-13 Power Requirements and Heat Dissipation—10BASE Ethernet Switching Modules
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-X6024-10FL-MT
24-port 10BASE-FL Ethernet
module
1.52 63.84 79.8 272.52 85.81 293.0
