Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
7-4
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
OL11954-01
Table 7-2 provides a list of Status menu options and a description of each.
Status Messages Screen
The Status Messages screen displays up to the 10 most recent status messages that
the phone has generated. You can access this screen at any time, even if the phone
has not finished starting up. Table 7-3 describes the status messages that might
appear. This table also includes actions you can take to address errors that are
indicated.
To display the Status Messages screen, follow these steps:
Procedure
Step 1 Press the Applications Menu button.
Step 2 Select Settings.
Step 3 Status.
Table 7-2 Model Information
Item Description
Status Messages Displays the Status Messages screen, which shows a
log of important system messages. For more
information, see the “Status Messages Screen”
section on page 7-4.
Network Statistics Displays the Network Statistics screen, which shows
Ethernet traffic statistics. For more information, see
the “Network Statistics Screen” section on
page 7-13.
Firmware Versions Displays the Firmware Versions screen, which shows
information about the firmware running on the
phone. For more information, see the “Firmware
Versions Screen” section on page 7-15.
802.1X Authentication
Status
Displays the time-stamped authentication successes
and failures. For more information, see the “Call
Statistics Screen” section on page 7-16
