3-13
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
OL11954-01
Chapter 3 Setting Up the Cisco Unified IP Phone
Installing the Cisco Unified IP Phone
Figure 3-3 Cisco Unified IP Phone Model 7906G Cable Connections
1 Network port (10/100 SW) 4 AC-to-DC power supply
2 Handset port 5 AC power cord
3 DC Adapter port (DC48V)
10/100 SW
2
5
4
1
3
154390
