Cisco ASR 9000 Serie

SUMMARY STEPS
1.
configure
2.
ipsla
3.
mpls lsp-monitor
4.
monitor monitor-id
5.
type mpls lsp ping
6.
path discover
7.
echo interval time
8.
echo maximum lsp selector ipv4 host address
9.
echo multipath bitmap-size size
10.
echo retry count
11.
echo timeout value
12.
path retry range
13.
path secondary frequency {both | connection-loss | timeout} value}
14.
scan period value
15.
commit
DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Enters IP SLA configuration mode and configures IP
service level agreements.
ipsla
Example:
RP/0/RSP0/CPU0:router(config)# ipsla
Step 2
Enters MPLS LSP monitor mode. From this mode you
can configure an LSP monitor instance, configure a
mpls lsp-monitor
Example:
RP/0/RSP0/CPU0:router(config-ipsla)# mpls lsp-monitor
Step 3
reaction for an LSP monitor instance, or schedule an
LSP monitor instance.
Configures an MPLS LSP monitor instance.
monitor monitor-id
Example:
RP/0/RSP0/CPU0:router(config-ipsla-mplslm)# monitor
2
Step 4
Verifies the end-to-end connectivity of a label switched
path (LSP) and the integrity of an MPLS network.
type mpls lsp ping
Example:
RP/0/RSP0/CPU0:router(config-ipsla-mplslm-def)# type
mpls lsp ping
Step 5
Cisco ASR 9000 Series Aggregation Services Router System Monitoring Configuration Guide, Release 4.2.x
277
Implementing IP Service Level Agreements
LSP Path Discovery
