Cisco Catalyst 2960-XR Configuration Guide

PurposeCommand or Action
supported when EtherChannel members are from different switches in the
switch stack.
channel-group 5 mode auto
• desirable —Unconditionally enables PAgP. It places the port into an active
negotiating state, in which the port starts negotiations with other ports by
sending PAgP packets. This keyword is not supported when EtherChannel
members are from different switches in the switch stack.
• on —Forces the port to channel without PAgP or LACP. In the on mode, an
EtherChannel exists only when a port group in the on mode is connected to
another port group in the on mode.
• non-silent —(Optional) If your switch is connected to a partner that is
PAgP-capable, configures the switch port for nonsilent operation when the
port is in the auto or desirable mode. If you do not specify non-silent, silent
is assumed. The silent setting is for connections to file servers or packet
analyzers. This setting allows PAgP to operate, to attach the port to a channel
group, and to use the port for transmission.
• active—Enables LACP only if a LACP device is detected. It places the port
into an active negotiating state in which the port starts negotiations with other
ports by sending LACP packets.
• passive —Enables LACP on the port and places it into a passive negotiating
state in which the port responds to LACP packets that it receives, but does not
start LACP packet negotiation.
Returns to privileged EXEC mode.end
Example:
Switch(config-if)# end
Step 6
Related Topics
EtherChannel Overview, on page 106
EtherChannel Modes, on page 107
EtherChannel on Switches, on page 108
EtherChannel Link Failover, on page 109
LACP Modes, on page 114
PAgP Modes , on page 111
Silent Mode, on page 112
EtherChannel Configuration Guidelines, on page 120
Default EtherChannel Configuration, on page 119
Layer 2 EtherChannel Configuration Guidelines, on page 122
Catalyst 2960-XR Switch Layer 2 Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29424-01 125
Configuring EtherChannels
Configuring Layer 2 EtherChannels

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
