Page #154 background imageLoading...
Page #154 background image
Related Topics
Understanding Link-State Tracking, on page 140
How to Configure Link-State Tracking, on page 143
Monitoring Link-State Tracking Status
Understanding Link-State Tracking
Link-state tracking, also known as trunk failover, binds the link state of multiple interfaces. Link-state tracking
can be with server NIC adapter teaming to provide redundancy in the network. When the server NIC adapters
are configured in a primary or secondary relationship, and the link is lost on the primary interface, network
connectivity is transparently changed to the secondary interface.
An interface can be an aggregation of ports (an EtherChannel) or a single physical port in either access
or trunk mode.
Note
Catalyst 2960-XR Switch Layer 2 Configuration Guide, Cisco IOS Release 15.0(2)EX1
140 OL-29424-01
Configuring Link-State Tracking
Understanding Link-State Tracking
