Cisco Catalyst 2960-XR Configuration Guide

DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Configures the maximum-aging time for all MST instances. The
maximum-aging time is the number of seconds a switch waits
spanning-tree mst max-age seconds
Example:
Switch(config)# spanning-tree mst max-age
40
Step 2
without receiving spanning-tree configuration messages before
attempting a reconfiguration.
For seconds, the range is 6 to 40; the default is 20.
Returns to privileged EXEC mode.end
Example:
Switch(config)# end
Step 3
Related Topics
Specifying the MST Region Configuration and Enabling MSTP, on page 59
Configuring the Maximum-Hop Count
Beginning in privileged EXEC mode, follow these steps to configure the maximum-hop count for all MST
instances. This procedure is optional.
Before You Begin
A multiple spanning tree (MST) must be specified and enabled on the switch. For instructions, see Related
Topics.
SUMMARY STEPS
1.
configure terminal
2.
spanning-tree mst max-hops hop-count
3.
end
Catalyst 2960-XR Switch Layer 2 Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29424-01 71
Configuring Multiple Spanning-Tree Protocol
Configuring the Maximum-Hop Count

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
