Page #158 background image
PurposeCommand or Action
upstream
Returns to privileged EXEC mode.end
Example:
Switch(config-if)# end
Step 5
Related Topics
Understanding Link-State Tracking, on page 140
Configuring Link-State Tracking: Example, on page 144
Restrictions for Configuring Link-State Tracking, on page 139
Monitoring Link-State Tracking
You can display link-state tracking status using the command in this table.
Table 19: Commands for Monitoring Link-State Tracking Status
DescriptionCommand
Displays the link-state group information.
show link state group [ number ] [detail]
Configuring Link-State Tracking: Example
This example shows how to create the link-state group 1 and configure the interfaces in the link-state group.
Switch# configure terminal
Switch(config)# link state track 1
Switch(config-if)# interface range gigabitethernet1/0/21-22
Switch(config-if)# link state group 1 upstream
Switch(config-if)# interface gigabitethernet1/0/1
Switch(config-if)# link state group 1 downstream
Switch(config-if)# interface gigabitethernet1/0/3
Switch(config-if)# link state group 1 downstream
Switch(config-if)# interface gigabitethernet1/0/5
Switch(config-if)# link state group 1 downstream
Switch(config-if)# end
Related Topics
Understanding Link-State Tracking, on page 140
How to Configure Link-State Tracking, on page 143
Monitoring Link-State Tracking Status
Catalyst 2960-XR Switch Layer 2 Configuration Guide, Cisco IOS Release 15.0(2)EX1
144 OL-29424-01
Configuring Link-State Tracking
