Cisco Catalyst 4500 Series Installation Guide

3-19
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Chapter 3 Installing the Switch in a Rack
System Ground Connection Guidelines
Step 6 Connect the switch to an appropriate ground. Refer to System Ground Connection
Guidelines, page 3-19. The system must have a ground connection before power
is supplied to the switch.
System Ground Connection Guidelines
A grounding pad with two system (earth) grounding holes is provided in an
enclosure near the left power supply on the Catalyst
4500 series switches. See
Figure 3-13 for the location of the grounding holes on the Catalyst 4503 switch,
Figure 3-14 for the location on the Catalyst 4506 switch, Figure 3-15 for the
location on the Catalyst 4507R switch, and Figure 3-16 for the location on the
Catalyst 4510R switch.
Figure 3-13 Catalyst 4503 Grounding Holes
1
13
1
13
1
13
1
13
79479
4506
UPLINK
1
UPLINK 2
AC
TIVE
LIN
E
AC
TIVE
LINE
ACT
IVE
RESET
UTILIZATION
STATUS
4503
WS-X4515 SUPERVISOR ENGINE IV
1
%
10
0
%
C
O
N
S
O
L
E
LINK
EJECT
FLASH
1
0
/1
0
0
M
G
T
Grounding
holes (2)

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
