Chapter 2 Preparing for Installation
Site-Planning Checklist
Note Although a class 3 device needs 15.4 W to power up, 17.3 W need to be generated
from the backplane in order to have 15.4 W at the switch port. 17.3 W comes from
the WS-X4248-RJ45V DC-DC converter’s efficiency (89%).
Site-Planning Checklist
Table 2-2 lists the site-planning activities that you should complete before you
install a Catalyst 4500 series switch. Completing each activity helps to ensure a
successful switch installation.
1 - IEEE class 3 device 17.3 W
total output power 284 W
Total heat dissipated by system = (284/.75) * 3.415 = 1293 BTUs/hr
Ta b l e 2-2 Site-Planning Checklist
Task No. Planning Activity Verified by Time Date
1 Space evaluation:
• Space and layout
• Floor covering
• Impact and vibration
• Lighting
• Maintenance access
2 Environmental evaluation:
• Ambient temperature
• Humidity
• Altitude
• Atmospheric contamination
• Airflow

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
