Cisco Catalyst 4500 Series Installation Guide

Appendix A Specifications
Catalyst 4506 Switch Specifications
A-4
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Switching Components
Backplane 60 Gbps full duplex
4 Gbps Uplinks
Port density 240 (max)
Inline power integrated support, 820 W per line card
Physical Characteristics
Dimensions (H x W x D) • 17.38 x 17.31 x 12.50 in. (44.13 x 43.97 x 31.70 cm)
• 10 RU
Weight Minimum weight: 40.5 lb (18.4 kg)
Maximum weight: 100 lb (45.4 kg)
Chassis and backplane = 36.5 lb (16.5 kg)
Fan tray: 4.0 lb (1.8 kg)
Airflow
Switch Right to left
Power supply Front to back
Power
PoE supplied –48 VDC
Power to Modules and fans 12 VDC
Power to backplane components 3.3 VDC
Redundancy
Supervisor engine no
Power supply 1 + 1
Table A-2 Catalyst 4506 Switch Specifications (continued)
Item Specification

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
