Cisco Catalyst 4500 Series Installation Guide

3-23
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Chapter 3 Installing the Switch in a Rack
System Ground Connection Guidelines
Parts and Required Tools
Note Some parts and required tools described in this section are not available from
Cisco
Systems. The grounding lug and associated screws are included with the
accessory kit.
To make an adequate grounding connection, you will need the following parts and
tools:
• Grounding lug—The grounding lug has two #10 AWG holes spaced 0.63 in
center to center. A Panduit LCDX6-10A-L or Pencom EL1033 lug may be
used if the lug from the accessory kit has been misplaced.
• Two M4 (metric) hex-head screws.
• One grounding wire (6 AWG recommended)—The length of the grounding
wires depends on the location of your switch within the site and its proximity
to proper grounding facilities.
• Number 2 Phillips screwdriver.
• Crimping tool—This tool must be large enough to accommodate the girth of
the grounding lug when you crimp the grounding cable into the lug.
• Wire-stripping tool.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
