Cisco Catalyst 4500 Series Installation Guide

Chapter 1 Product Overview
Supervisor Engines
1-20
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Supervisor Engines
The following supervisor engines are available for the Catalyst 4500 series
switches:
• Supervisor Engine II (WS-X4013) (Figure 1-5)
• Supervisor Engine II-Plus (WS-X4013+) (Figure 1-6)
• Supervisor Engine II-Plus TS (WS-X4013+TS) (Figure 1-7)
• Supervisor Engine II-Plus 10GE (WS-X4013+10GE) (Figure 1-8)
• Supervisor Engine III (WS-X4014) (Figure 1-9)
• Supervisor Engine IV (WS-X4515) (Figure 1-10)
• Supervisor Engine V (WS-X4516) (Figure 1-11)
• Supervisor Engine V-10GE (WS-X4516-10GE) (Figure 1-12)
Note E-series supervisor engines may in some cases also work on Catalyst 4500 series
systems, refer to the installation note for your supervisor engine for details.
The Catalyst 4500 series supervisor engines have the following features:
Ta b l e 1-5 Supervisor Engine Features
Feature Description
Data path and control Available on all network interfaces
Management functions Interface monitoring
Environmental status
SNMP and console/Telnet interface
MAC addresses supported 32,768 per system (Cisco IOS only)
VLANS Up to 4,096 VLANs with IEEE 802.1Q VLAN tagging on all ports and
VLAN Trunking Protocol (VTP)
Port aggregation PAgP
1
for 100-Mbps and 1000-Mbps EtherChannel
SNMP Full implementation, including entity-MIB, all relevant standard MIBs,
and all relevant Cisco MIBs

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
