Cisco Catalyst 4500 Series Installation Guide

Chapter 1 Product Overview
Fan Assembly
1-30
Catalyst 4500 Series Switches Installation Guide
78-14409-08
For more information, refer to Using the Compact Flash on the Catalyst 4000
Family Supervisor Engine
III and IV at the following URL:
http://www.cisco.com/en/US/docs/switches/lan/catalyst4500/hardware/configur
ation/notes/OL_2788.html
Fan Assembly
Note For complete environmental specifications, including airflow requirements, see
Appendix A, “Specifications.”
The system fan assembly provides cooling air for the internal chassis components.
The fan assembly is a tray of fans that you can insert and remove from the chassis
while the system is on line. The Catalyst
4503 fan assembly has two fans, the
Catalyst
4506 fan assembly has four fans, the Catalyst 4507R fan assembly has
six fans, and the Catalyst
4510R fan assembly has eight fans. The fans draw in
fresh air from one side and exhaust air on the other side. Catalyst
4503 airflow is
shown in
Figure 1-13. Catalyst 4506 airflow is shown in Figure 1-14.
Catalyst 4507R airflow is shown in Figure 1-15. Catalyst 4510R airflow is shown
in Figure 1-16.
Caution You must install module filler plates on unused switching module slots to ensure
proper airflow.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
