Cisco Catalyst 4500 Series Installation Guide

A-7
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Appendix A Specifications
Catalyst 4510R Switch Specifications
Catalyst 4510R Switch Specifications
Table A-4 lists the Catalyst 4510R switch specifications.
Ta b l e A-4 Catalyst 4510R Switch Specifications
Item Specification
Environmental
Temperature,
ambient operating
ambient nonoperating and storage
32 to 104°F (0 to 40°C)
–40 to 167°F (–40 to 75°C)
Humidity (RH), ambient (noncondensing):
operating
nonoperating and storage
10 to 90%
5 to 95%
Altitude:
operating
nonoperating
–500 to 6500 ft (–150 to 2000 m)
–1000 to 30,000 ft (–300 to 9150 m)
Switching Components
Backplane 88 Gbps full duplex with Supervisor Engine V,
96 Gbps with Supervisor Engine V-10GE
8 Gbps Uplinks with Supervisor Engine V
20 Gbps Uplinks with Supervisor Engine V-10GE
Port density 340 maximum using a Supervisor Engine V and a
WS-X4302-GB in the Flex-Slot
386 maximum using a Supervisor Engine V-10GE
Inline power integrated support, 820 W per line card
Physical Characteristics
Dimensions (H x W x D) • 24.35 x 17.31 x 12.50 in. (61.84 x 43.97 x 31.70 cm)
• 14 RU
Weight Minimum weight: 51.5 lb (23.4 kg)
Maximum weight: 108 lb (49.8 kg)
Chassis and backplane: 45.5 lb (20.6 kg)
Fan tray: 6.0 lb (2.7 kg)

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
