Cisco Catalyst 4500 Series Installation Guide

5-9
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Chapter 5 Troubleshooting
Troubleshooting Backplane Modules
C4K_IOSMODPORTMAN-4-FANTRAYPARTIALFAILURE
C4K_IOSMODPORTMAN-4-FANTRAYREMOVED
C4K_SUPERVISOR-3-FANTRAYREADFAILED
C4K_SUPERVISOR-3-FANTRAYSEEPROMREADFAILED
C4K_SUPERVISOR-3-FANTRAYSEEPROMINVALID
C4K_IOSMODPORTMAN-4-TEMPHIGH
C4K_IOSMODPORTMAN-4-TEMPUNDERCRITICAL
C4K_CHASSIS-2-OVERHEATINGSHUTDOWN
Step 4 Determine whether the airflow is restricted or if the ambient temperature in the
room is too warm.
Step 5 Determine whether the power supply is functioning properly. See the
“Troubleshooting the Power Supply” section on page 5-6.
Step 6 Verify that the fan assembly is properly seated in the backplane by loosening the
captive installation screws, removing the fan assembly, and reinstalling it.
Step 7 Restart the system.
Step 8 Verify that all fans are operating. You should hear the fans at system start.
Step 9 If the system is still detecting a fan assembly failure, contact the Cisco TAC for
assistance.
Troubleshooting Backplane Modules
The Cisco Catalyst 4500 Series redundancy scheme uses removable redundancy
modules (also called mux-buffers), on the passive backplane to switch traffic to
the active supervisor engine. There is one redundancy module per switching
module. Redundancy modules and a redundant clock ship standard with every
Cisco Catalyst 4507R and 4510R chassis. Spare redundancy modules
(C4K-MUX=) and a clock module (C4K-CLOCK=) are available for
serviceability.
The following conditions indicate that you may need to replace the redundancy
modules and clock module:

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
