Cisco Catalyst 4500 Series Installation Guide

1-21
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Chapter 1 Product Overview
Supervisor Engines
RMON The first four groups (Ethernet statistics, Alarms, Events, and History)
are on a per-port basis without an optional RMON processing module
SPAN
2
Supported, which allows you to redirect traffic from any port or VLAN
to a SPAN destination port
Performance management Information provided
Hot-swappable Supported. On non-redundant systems, packets are not forwarded while
the supervisor engine is removed, and a system reboot occurs when a
supervisor engine is reinserted.
Gigabit Ethernet (using a
GBIC or SFP)
Includes two (four on WS-X4516-10GE and WS-X4013+10GE) Gigabit
Ethernet (1000BASE-X) interfaces for backbone interconnection of
high-performance switches and routers
10-Gigabit Ethernet
(WS-X4516-10GE and
WS-X4013+10GE)
Includes two 10 Gigabit Ethernet interfaces for backbone
interconnection of high-performance switches and routers
Forwarding Layer 2, 3, and 4 forwarding (Cisco IOS only)
Supervisor Engine II 24-Gbps, 18 Mpps full-duplex Gigabit Ethernet switching engine
Supervisor Engine II-Plus 64 Gbps, 48 Mpps (with Catalyst 4506 and 4507R, or 28-Gbps, 21 Mpps
with Catalyst 4503) full-duplex Gigabit Ethernet switching engine
Supervisor
Engine
II-Plus TS
64 Gbps, 48 Mpps (with Catalyst 4503 only) full-duplex Gigabit
Ethernet switching engine
Supervisor
Engine
II-Plus 10GE
108 Gbps, 81 Mpps full-duplex Gigabit Ethernet switching engine
Supervisor Engine III 64 Gbps, 48 Mpps (with Catalyst 4506 and 4507R, or 28-Gbps, 21 Mpps
with Catalyst 4503) full-duplex Gigabit Ethernet switching engine
Supervisor Engine IV 64 Gbps, 48 Mpps (with Catalyst 4506 and 4507R, or 28-Gbps, 21 Mpps
with Catalyst 4503) full-duplex Gigabit Ethernet switching engine
Table 1-5 Supervisor Engine Features (continued)
Feature Description

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
