Chapter 1 Product Overview
Switch Features
Switching module
support (continued)
• 32-port 10/100-Mbps Fast Ethernet plus 2-port 1000BASE-X Layer 3
Gigabit Ethernet routing
module (WS-X4232-L3)
• 32-port 10/100-Mbps Fast Ethernet switching module with modular uplink
support (WS-X4232-RJ-XX)
– 4-port MT-RJ uplink module (WS-U4504-FX-MT) (optional)
• 2-port Gigabit Ethernet switching module (WS-X4302-GB)
• 6-port 1000BASE-X Gigabit Ethernet switching module (WS-X4306-GB)
• 6-port Gigabit Ethernet switching module (WS-X4506-GB-T)
• 12-port 1000BASE-T plus 2-port 1000BASE-X Gigabit Ethernet switching
module (WS-X4412-2GB-T)
• 18-port Gigabit Ethernet switching module (WS-X4418-GB)
• 24-port 10/100/1000BASE-T Gigabit Ethernet switching module
(WS-X4424-GB-RJ45)
• 48-port Gigabit Ethernet 1000 BASE LX (SPF) switching module
(WS-X4448-GB-LX)
• 48-port 10/100/1000BASE-T Gigabit Ethernet switching module
(WS-X4448-GB-RJ45)
• 24-port IEEE 802.3af-compliant PoE 10/100/1000BASE-T RJ-45 switching
module (WS-X4524-GB-RJ45V)
• 48-port 10/100/1000BASE-T Gigabit Ethernet switching module
(WS-X4548-GB-RJ45)
• 48-port Gigabit Ethernet switching module (WS-X4448-GB-SFP)
• 48-port IEEE 802.3af compliant PoE 10/100/1000BASE-T Gigabit Ethernet
switching module (WS-X4548-GB-RJ45V)
• Access Gateway Module (WS-X4604-GWY)
1. You will need to configure the 1400 W DC input current as appropriate for the model of switch. Refer to Appendix A,
“Specifications.”
2. 1000W AC and 1300W AC power supplies will fit and function; however, power management is cautioned and ony some
configurations will have adequate power. Please refer to the Cisco Power Calculator at
http://tools.cisco.com/cpc/ before
configuring these power supplies.
Table 1-4 Features of the Catalyst 4510R Switch (continued)
Feature Description

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
