Catalyst 4503-Specific Power Usage
(data only)
Two modules minimum required @ –40.5 VDC input
One 15A module minimum required @ –44 VDC input
Maximum draw 475 W
Maximum input 609 W total / # of modules = W per module
Current draw at –40.5 V (min voltage)
Current draw at –72 V (max voltage)
15 A total / # of modules = A per module
8.5 A total / # of modules = A per module
Max heat dissipation at 609 W 2078 BTUs
Catalyst 4506-Specific Power Usage
(data only)
Two modules minimum required @ –44 VDC input
Three modules minimum required @ –40.5 VDC input
Maximum draw (data only) 850 W
Maximum input 1076 W total / # of modules = W per module
Current draw at –40.5 V (min voltage)
Current draw at –72 V (max voltage)
26.6 A total / # of modules = A per module
15 A total / # of modules = A per module
Max heat dissipation at 1076 W 3671 BTUs
Catalyst 4507R-Specific Power Usage
(data only)
Three modules minimum required
Maximum draw (data only) 1080 W
Max input is 1080 W 1367 W total / # of modules = W per module
Current draw at –40.5 V (min voltage)
Current draw at –72 V (max voltage)
33.75 A total / # of modules = A per module
19 A total / # of modules = A per module
Max heat dissipation 1367 W 4665 BTUs
Table A-9 1400 W DC Triple-Input Power Supply Specifications (continued)
Item Specification
