Cisco Catalyst 4500 Series Installation Guide

IN-3
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Index
D
DC-input power supplies
connecting system ground 3-23
description 1-31
environmental monitoring 1-35
figure 1-32, 1-33, 4-4
handling (figure) 4-15
installing 4-16
removing 4-11
replacing 4-16
See also AC-input power supplies
troubleshooting 5-6
verifying operation 4-18
dimensions
Catalyst 4503 switches (table) A-2
Catalyst 4506 switches (table) A-4
Catalyst 4507 switches (table) A-5, A-6
disconnecting
ground connections (warning) 4-13
documentation
conventions xi
E
electrostatic discharge
see ESD
environmental monitoring
power supplies 1-35
ESD
cabling and preventing damage 2-2, 2-3
Ethernet management ports
figure 1-22
LEDs 5-4
troubleshooting 5-4
F
FAIL LEDs
checking 4-10
verifying power supply status 4-18
fan assemblies
booting 5-2
Catalyst 4503 switches (figure) 1-3
Catalyst 4506 switches (figure) 1-7
Catalyst 4507 switches (figure) 1-11, 1-15
description 1-27
installing 4-23
power supplies 1-35
removing 4-23
replacing 4-22
troubleshooting 5-8
verifying installation 4-24
FAN OK LED
checking 4-10
description 1-34
Fast Ethernet
See 100BASE-T

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
