Cisco Catalyst 4500 Series Installation Guide

1-27
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Chapter 1 Product Overview
Supervisor Engines
LEDs
Table 1-6 describes the supervisor engine LEDs.
Gigabit Ethernet Uplink Ports
The Gigabit Ethernet uplink ports operate in full-duplex mode only. GBICs have
SC connectors to interface with multimode fiber (MMF) and single-mode fiber
(SMF) cable. For more information about GBICs, refer to the Catalyst
4500
Series Module Installation Guide.
Ta b l e 1-6 Supervisor Engine LEDs
LED Color/State Description
STATUS Indicates the results of a series of self-tests:
Green All diagnostic tests passed.
Red A test failed.
Orange System boot or diagnostic test is in progress.
Off Module is disabled.
UTILIZATION Green 1–100% If the switch is operational, this display indicates the current
traffic load over the backplane (as an approximate percentage).
LINK Indicates the status of the 10/100BASE-T port,
10/100/1000BASE-T or uplink ports:
Green The link is operational.
Orange The link is disabled by user.
Flashing orange The power-on self-test indicates a faulty port.
Off No signal is detected or there is a link configuration failure.
ACTIVE Indicates whether the uplink port is active or not:
Green The port is active.
Off The port is not active.
ACTIVE The LED to the right of the uplink ports is only used in switches
with two supervisors. The LED lights on the active supervisor.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
