Cisco Catalyst 4500 Series Installation Guide

Chapter 1 Product Overview
Power Supplies
1-40
Catalyst 4500 Series Switches Installation Guide
78-14409-08
The maximum total input current is 42.5A and the maximum ambient temperature
is 55 C. To determine total maximum input power to a supply, add up the active
individual module input power ratings.
Table 1-9 provides output information for
these modes, given two supplies working in combined mode. Table 1-10 provides
output information for these modes, given two supplies working in redundant
mode.
Note In a redundant configuration with all inputs supplied, there must be a 100 W
minimum system load or the OUTPUT FAIL LED shows a false failure.
The C4500 1400 W DC Triple Input SP Power Supply requires a minimum draw
from the system that it is installed in.
Table 1-11 shows
Ta b l e 1-9 Combined Mode Power Supply Configuration
(2450 W Max Output Power)
Input
Number
Maximum Input Current
Maximum Input
Power @ –44 V DC
1 12.5 A @ –44 V DC 550 W
2 15 A @ –44 V DC 660 W
3 15 A @ –44 V DC 660 W
Ta b l e 1-10 Dual Redundant Mode Power Supply Configuration
(1400 W Max Output Power)
Input
Number
Approximate
Input Current
Approximate Input
Power @ –40.5 V DC
Approximate Input
Power @ –44 V DC
1 6.25 A @
–40.5 / –44 V DC
253 W 275 W
2 7.5 A @ –40.5 /
–44 V DC
304 W 330 W
3 7.5 A @ –40.5 /
–44 V DC
304 W 330 W

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
