Cisco Catalyst 8300 Series User Manual

Step 5 Insert the USB console cable and power into your system. The Device manager refreshes and indicates the newly-detected
COM port.
Step 6 Open a terminal emulator and click the Serial connection type. Input the values for Serial Line and Speed (or Baud Rate).
Step 7 Click Open.
Step 8 The terminal emulator opens. Click Enter to view the console output response.
The USB console is ready for use.
Install the Silicon Labs Mac USB Device Driver
Step 1 Go to the Silicon Labs website (www.silabs.com/developers/usb-to-uart-bridge-vcp-drivers?tab=downloads), and click
CP210x VCP Mac OSX Driver.
Step 2 Click the Downloads folder, then click the macOS_VCP_Driver folder, and double-click the SiLabsUSBDriverDisk.dmg
program.
Step 3 Click Install CP210X VCP Driver, and then click Open. The Driver Installer begins.
Step 4 Follow installer instructions. Click Continue, scroll all the way down, then click Continue, and click Agree.
Step 5 Click Continue, and enter your password. Then click Install Helper, and click Close.
Step 6 Insert the USB console cable and power into your system..
Step 7 Open a terminal and type cd/dev, and then type ls-ltr. Serial port tty.SLAB_USBtoUART appears.
Step 8 Type screen/dev/tty.SLAB_USBtoUART <baudrate> to see console output. Console will show response upon first Enter
key if there is no output.
The USB console is ready for use.
Connect WAN and LAN Interfaces
This section describes how to connect WAN and LAN interface cables. Before you connect the interface
cables, refer to the following warning statements:
Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
Statement 1036.
Warning
Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected
at the network interface. Statement 1037.
Warning
Hardware Installation Guide for Cisco Catalyst 8300 Series Edge Platforms
51
Install and Connect
Install the Silicon Labs Mac USB Device Driver

Cisco Catalyst 8300 Series Specifications

General

Software	Cisco IOS XE
Interface Modules	Modular
WAN Ports	Varies based on module selection
LAN Ports	Varies based on module selection
Redundancy	Yes, with dual power supplies and modular components
Security	Integrated threat defense, encryption, and secure boot
Management	Cisco DNA Center, CLI, SNMP, REST APIs
Form Factor	Rack-mountable
Rack Height	1RU or 2RU
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, Serial
Power Supply	Redundant power supply options available
Key Features	SD-WAN, advanced security
Product Family	Catalyst
Port Density	Varies based on module selection
Dimensions	Varies by model
Weight	Varies by model and module selection
