Figure 35: Install the Cover on the C8300-2N2S-4T2X|6T
Chassis
cover
1
Screws2
Chassis3
Remove and Replace DDR DIMMs
To access the DIMMs, you must remove the chassis cover as described in the Access and Install Modules
section.
Always wear an ESD-preventive wrist strap and ensure that it makes good contact with your skin when
you remove or install DIMMs. Connect the equipment end of the wrist strap to the metal part of the
chassis.
Caution
Hardware Installation Guide for Cisco Catalyst 8300 Series Edge Platforms
60
Install Internal Components and Field Replaceable Units
Remove and Replace DDR DIMMs
