Cisco Catalyst Wireless 9163E - Power Sources

Table 3: CW9163E Access Point Supported 6-GHz External Antennas
Antenna Type6–GHz
Antenna
Gain
(dBi)
5–GHz
Antenna
Gain
(dBi)
2.4–GHz
Antenna
Gain
(dBi)
PID
Direct Attach Omni Directional Antenna, Tri-band884CW-ANT-O1-NS-00
Table 4: CW9163E Access Point Supported External Antennas
Antenna TypeAntenna Gain
(dBi)
PID
Wall or Pole Attach, AFC compliant, GNSS
Antenna with 10-ft. integrated cable
2CW-ANT-GPS2-S-00
For installation instructions and detailed information on any of these antennas, refer to the antenna guide at:
http://www.cisco.com/c/en/us/support/wireless/aironet-antennas-accessories/
products-installation-guides-list.html
Use of Non-Cisco Antennas
RF connectivity and compliance of third-party antennas is the user’s responsibility. Cisco does not recommend
any third-party antennas, and the Cisco Technical Assistance Center will not be able to provide any support
for third-party antennas. Cisco’s FCC Part 15 compliance is only guaranteed with Cisco antennas or antennas
that are of the same design and gain as Cisco antennas.
Power Sources
You can power the CW9163E AP with Power over Ethernet (PoE) and select power injectors. For more
information, see Powering the Access Point, on page 28.
Statement 1033—Safety Extra-Low Voltage (SELV)—IEC 60950/ES1–IEC 62368 DC Power Supply
To reduce the risk of electric shock, connect the unit to a DC power source that complies with the SELV
requirements in IEC 60950-based safety standards or ES1 and PS1 requirements in IEC 62368-based safety
standards or to a Class 2 power supply.
Warning
For PoE options and their corresponding modes of operation, see Table 9: Cisco Catalyst Wireless 9163E AP
Reduced Power Feature Matrix, on page 29.
Caution
Cisco Catalyst Wireless 9163E Access Point Hardware Installation and Deployment Guide
9
Hardware Features
Power Sources
