Appendix A Specifications
Electrical Specifications
A-2
Cisco 11500 Series Content Services Switch Hardware Installation Guide
78-16421-01
Electrical Specifications
Table A-1 describes the CSS 11501, CSS 11503, and CSS 11506 AC electrical
specifications. The CSS 11501, CSS 11503, and CSS 11506 AC power supplies
autosense for voltage and frequency.
Table A-2 describes the CSS 11503 and CSS 11506 DC electrical specifications.
Table A-1 AC Electrical Specifications
AC Specification CSS 11501 CSS 11503 CSS 11506
Input Voltage AC 100 to 240 VAC
50 to 60 Hz
100 to 240 VAC
50 to 60 Hz
100 to 240 VAC
50 to 60 Hz
Current AC (max@
100 VAC)
1.6 Amps 5 Amps 9 Amps
Power Consumption
(maximum)
150VA 430VA 860VA
Heat Dissipation 512 BTU/hr 1468 BTU/hr 2936 BTU/hr
Table A-2 DC Electrical Specifications
DC Specification CSS 11503 CSS 11506
Voltage DC -48.0 to -60.0 VDC -48.0 to -60.0 VDC
Current DC (maximum) 9 Amps 18 Amps
Power Consumption
(maximum)
430 VA 860 VA
Heat Dissipation 1468 BTU/hr 2936 BTU/hr
