Appendix B Cable Connector Pinouts
RJ-45 RS-232 Console Port Pinouts
RJ-45 RS-232 Console Port Pinouts
Table B-2 lists the RJ-45 RS-232 Serial connector pinouts for the Console port on
the CSS 11501 front panel and the CSS 11503 or CSS 11506 Switch Control
Module (SCM).
The following sections provide the pinouts for:
• Connecting the Console Port to a PC
• Connecting the Console Port to a Terminal
• Connecting the Console Port to a Modem
Table B-2 RJ-45 RS-232 Serial Connector Pinouts for the Console Port
Signal Name Pin Number
RTS 1
DTR 2
TXD 3
GND 4
GND 5
RXD 6
DSR 7
CTS 8
