Appendix A Specifications
Physical Specifications
A-4
Cisco 11500 Series Content Services Switch Hardware Installation Guide
78-16421-01
Physical Specifications
Table A-4 describes the CSS 11501, CSS 11503, and CSS 11506 physical
specifications.
Table A-4 Physical Specifications
Specification CSS 11501 CSS 11503 CSS 11506
Chassis Dimensions
(H x W x D)
1.72” x 17.29” x 18.1” 3.5” x 17.25” x 18.5” 8.25” x 17.25” x 14”
Chassis Shipping Weight 21.5 lbs. (9.77 kg) 42.85 lbs. (19.44 kg)
(base system containing
one SCM and two I/O
modules plus accessory
box)
67.65 lbs. (30.69 kg)
(base system containing
two power supplies,
one SCM, five I/O
modules, and mounting
brackets plus accessory
box)
Chassis Weight Fully
Configured
18.0 lbs. 33.3 lbs.
(base system containing
one SCM and two I/O
modules)
57.7 lbs.
(base system containing
two power supplies,
one SCM, and five I/O
modules)
