Appendix B Cable Connector Pinouts
RJ-45 RS-232 Console Port Pinouts
Connecting the Console Port to a Terminal
To connect the console port to a terminal, use an RJ-45 to RJ-45 rollover cable
and an RJ-45 to DB-25 female DTE adapter. The DTE adapter is part of the
accessory kit.
Table B-4 lists the signals of the console port and terminal device, and the pinouts
of the rollover cable and the DTE adapter interfaces.
Table B-4 Console Port to Terminal Signals and Pinouts
Console
Port Signal
Console Port to
RJ-45 Rollover
Cable Pinouts
RJ-45 Rollover
Cable to RJ-45
DTE Adapter
Pinouts
DB-25 DTE
Adapter to
Terminal
Pinouts
Terminal
Device Signal
RTS185CTS
DTR 2 7 6 DSR
TXD363RXD
GND 4 5 7 GND
GND 5 4 7 GND
RXD632TXD
DSR7320DTR
CTS814RTS
