2-17
Cisco 11500 Series Content Services Switch Hardware Installation Guide
78-16421-01
Chapter 2 Cabling and Troubleshooting the CSS
Cabling the CSS 11503 and CSS 11506 Modules
Table 2-3 describes the FEM LEDs and their indications.
Note If all of the FEM Link and Duplex LEDs blink synchronously, the module has
failed.
Gigabit Ethernet Module Connectors and LEDs
The Gigabit Ethernet Module (GEM), model CSS5-IOM-2GE, contains two
1000-Mbps SFP GBICs; 1000BASE-SX or LX with LC-type connectors, or
1000BASE-T with RJ-45 connectors.
The GEM can use the following GBICs with LC-type connectors:
• Long-wavelength SFP GBICs (CSS5-GBIC-LX). The longwave length
transceiver (1000BASE-LX) can reach 1,804.4 ft. (550 m) for all multimode
media types. For single-mode fiber, the distance is 16,404 ft. (5,000 m).
• Short-wavelength SFP GBICs (CSS5-GBIC-SX). The transceiver distance
can reach from 721.8 ft. ( 220 m) to 1,640.4 ft. (500 m), depending on the
quality of the fiber.
Warning
Because invisible radiation may be emitted from the aperture of the port when
no fiber cable is connected, avoid exposure to radiation and do not stare into
open apertures.
Table 2-3 Fast Ethernet Module LED Descriptions
LED Name Color State Indicates
Link Green Off No link established
On Link established but no activity
Blinking Link established with transmit or receive
activity
Duplex Green Off Port is operating at half duplex
On Port is operating at full duplex
