Appendix B Cable Connector Pinouts
RJ-45 Management Connector Pinouts
RJ-45 Management Connector Pinouts
Table B-6 lists the RJ-45 10-MB Ethernet Management connector pinouts on the
CSS 11501 front panel and the CSS 11503 or CSS 11506 SCM.
Table B-6 RJ-45 Management Connector Pinouts
Signal Name Pin Number
TX + 1
TX - 2
RX + 3
Unconnected 4
Unconnected 5
RX - 6
Unconnected 7
Unconnected 8
