Chapter 2 Cabling and Troubleshooting the CSS
Cabling the CSS 11503 and CSS 11506 Modules
2-16
Cisco 11500 Series Content Services Switch Hardware Installation Guide
78-16421-01
Figure 2-6 illustrates the LEDs and connectors on the 16-port FEM.
Figure 2-6 16-Port Fast Ethernet Module Connectors and LEDs
1 RJ-45 Ethernet
10BASE-T/100BASE-TX
connector 1 (connector 2 is
shown directly above it)
4 RJ-45 Ethernet
10BASE-T/100BASE-TX connector
16 (connector 15 is shown directly
below it)
2 Link LED (on each connector) 5 Spring-loaded screw (one of two)
3 Duplex LED (on each
connector)
6 Ejector (one of two)
CSS5-10M-16FE
DPLX
16 Fast Ethernet
DPLX
LINK
LINK
1
2
4
5
15
14
13
12
11
10
9
8
7
6
3
CSS5-10M-16FE
DPLX
16 Fast Ethernet
DPLX
LINK
LINK
59533
1
2
3
3
6
2
4
5
