Appendix B Cable Connector Pinouts
RJ-45 RS-232 Console Port Pinouts
B-4
Cisco 11500 Series Content Services Switch Hardware Installation Guide
78-16421-01
Connecting the Console Port to a PC
To connect the console port to a PC running terminal emulation software, use an
RJ-45 to RJ-45 rollover cable and an RJ-45 to DB-9 female DTE adapter labeled
Terminal. The DTE adapter is part of the accessory kit.
Table B-3 lists the signals of the console port and PC console device, and the
pinouts of the rollover cable and the DTE adapter interfaces.
Table B-3 Console Port to PC Signals and Pinouts
Console
Port Signal
Console Port to
RJ-45 Rollover
Cable Pinouts
RJ-45 Rollover
Cable to RJ-45
DTE Adapter
Pinouts
DB-9 DTE
Adapter to PC
Console
Device Pinouts
PC Console
Device Signal
RTS188CTS
DTR 2 7 6 DSR
TXD362RXD
GND 4 5 5 GND
GND 5 4 5 GND
RXD633TXD
DSR 7 3 4 DTR
CTS817RTS
