Chapter 2 Cabling and Troubleshooting the CSS
Cabling the CSS 11503 and CSS 11506 Modules
2-10
Cisco 11500 Series Content Services Switch Hardware Installation Guide
78-16421-01
Figure 2-3 illustrates a fully-configured CSS 11506 and its components.
Figure 2-3 CSS 11506 Content Services Switch
1 Fan module 4 Slot 2 for an SCM or I/O module
2 Slot 1 for the SCM 5 Slot 6
1
1. Slots 3 through 6 are for I/O modules, including SAMs and SSL modules.
3 Switch Modules in slots 7 and 8 6 Power supplies 1, 2, and 3
