9.3. Install the fan module
1. Loosen the two wing nuts, but not remove them.
Wing nuts
2. Lower the fan module down onto the screws with wing
nuts, and then push it into the groove.
Wing nuts
3. Tighten the two wing nuts.
×2 ×2
