21. Mount the side panels
Side panels (Box: D)
2x side panels
4x
×2
1. Insert the side panels as shown. Align them so that the top and bottom gaps are equal.
2. Fasten each panel with two screws
(M4x10, Torx T20).
2x for each panel
(M4x10, Torx T20)
