18. Mount the top covers

Covers (Box: A)

Place the top covers as shown in the illustration. Left and

right first, then the center top cover. The covers shall rest on

the rubber grommets an both ends.

To avoid rattling noise, make sure the covers doesn’t touch

any metal parts. Also, make sure not to interfere with the

antenna cables.

2x top cover (left and right)

1x top cover (center)
