10. Mount the top brackets
Top brackets (Box: Center kit)
2x top bracket
There is a small bracket on each upper corner. Fasten the
brackets with two screws each (M4x8, Torx T20).
4x
×2
2x for each bracket
(M4x8, Torx T20)
