Cisco WAP125 Administrator's Guide

The configuration utility header contains standard information and appears at the top of every page. The header
provides these buttons:
DescriptionButton Name
The account name (Administrator or Guest) of the
user logged into the WAP device. The factory default
user name is cisco.
(User)
Hover the mouse pointer over the button, and select
a language. The factory default language is English.
(Language)
Click to log out of the configuration utility.
Click to show the WAP device type and version
number.
Click to show the context-sensitive online help. The
online help is designed to be viewed with browsers
using UTF-8 encoding. If the online help shows errant
characters, verify that the encoding settings on your
browser are set to UTF-8.
Navigation Pane
A navigation pane, or main menu, is located on the left side of each page. The navigation pane is a list on the
top-level features of the WAP device. If a main menu item is preceded by an arrow, select to expand and
display the submenu of each group. You can then select the desired submenu item to open the associated page.
Management Buttons
The following table describes the commonly-used buttons that appear on various pages in the system:
DescriptionButton Name
Adds a new entry to a table or database.Add
Cancels a change made to the page.Cancel
Clears all entries in a log table.Clear All
Deletes an entry in a table.Delete
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
7
Getting Started
Navigation Pane

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
