Cisco WAP125 Administrator's Guide

Changing Password
For security reasons, you are required to change the administrative password at a set interval. You will need
to access this page when the Password Aging Time is up.
Password complexity is enabled by default. The minimum password complexity requirements are shown on
the Change Password page. The new password must comply with the default complexity rules, or it can be
disabled temporarily by disabling Password Complexity. See Security, on page 30 for more information.
To change the default password, configure the following:
• Old Password — Enter the current password (default is cisco).
• New Password — Enter a new password.
• Confirm Password — Enter the new password again for confirmation.
• Password Strength Meter — Displays the strength of the new password.
• Password Complexity — The password complexity is enabled by default and requires that the new
password conform to the following complexity settings:
◦
Is different from the user name.
◦
Is different from the current password.
◦
Has a minimum length of eight characters.
◦
Contains characters from at least three character classes (uppercase letters, lowercase letters,
numbers, and special characters available on a standard keyboard).
Check Disable to disable the password complexity rules. However, we strongly recommend that you keep
the password complexity rules enabled.
Note
TCP/UDP Service
The TCP/UDP Service table displays the protocols and services operating on the WAP.
• Service — The service name.
• Protocol — The underlying transport protocol that the service uses (TCP or UDP).
• Local IP Address — The local IP address of the connected device. All indicates that any IP address on
the device can use this service.
• Local Port — The local port number.
• Remote IP Address — The IP address of a remote host using this service. All indicates that the service
is available to all remote hosts that access the system.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
4
Getting Started
Changing Password

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
