Cisco WAP125 Administrator's Guide

CHAPTER 6
Access Control
This chapter describes how to configure the ACL and the quality of service (QoS) feature on the WAP device.
It contains the following topics:
•
ACL, page 65
•
Client QoS, page 73
•
Guest Access, page 80
ACL
Access Control Lists (ACLs) are a collection of permit and deny conditions, called rules, that provide security
by blocking unauthorized users and allowing authorized users to access specific resources. ACLs can block
any unwarranted attempts to reach network resources.
The WAP device supports up to 50 IPv4, IPv6, and MAC ACLs and up to 10 rules in each ACL. Each ACL
supports multiple interfaces.
IPv4 and IPv6 ACLs
Each ACL is a set of rules applied to traffic received by the WAP device. Each rule specifies whether the
contents of a given field should be used to permit or deny access to the network. Rules can be based on various
criteria and may apply to one or more fields within a packet, such as the source or destination IP address, the
source or destination port, or the protocol carried in the packet. The IP ACLs classify traffic for Layers 3 and
4.
There is an implicit deny at the end of every rule created. To avoid denying all, we strongly recommend
that you add a permit rule to the ACL to allow traffic.
Note
MAC ACLs
MAC ACLs are Layer 2 ACLs. You can configure the rules to inspect fields of a frame such as the source or
destination MAC address, the VLAN ID, or the class of service. When a frame enters the WAP device port,
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
65

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
