Cisco WAP125 Administrator's Guide

Step 8
Click Save.
Configure IPv6 ACLs
To configure an IPv6 ACL:
Step 1
Select Access Control > ACL.
Step 2
Click ✚ to add an ACL.
Step 3
In the ACL name field, enter the name of the ACL.
Step 4
Choose IPv6 as the ACL type from the ACL Type list. The IPv4 ACL's control access to the network resources are based
on the Layer 3 and Layer 4 criteria.
Step 5
Click ✚ and select the associated interfaces to apply the ACL. Next, click OK. If you want to change the associated
interfaces, you can click ━ to delete the selected interface then click ✚ to choose new associated interfaces.
Step 6
Click More to view the configuration parameters. Click ✚ to add a rule and configure the following:
If no rules are added, the DUT denies all traffic by
default.
Note
• Rule Priority — When an ACL has multiple rules, the rules are applied to the packet or frame in order of priority.
A smaller number means a higher priority. The priority of the new rule will be the lowest of all explicit rules. You
can click the up or down button to change its priority. Note that there is always an implicit rule denying all traffic
with lowest priority.
• Action — Choose whether to Deny or Permit the action. The default action is Deny.
When you choose Permit, the rule allows all traffic that meets the rule criteria to enter the WAP device. Traffic
that does not meet the criteria is dropped.
When you choose Deny, the rule blocks all traffic that meets the rule criteria from entering the WAP device. Traffic
that does not meet the criteria is forwarded unless this rule is the final rule. Because there is an implicit deny all
rule at the end of every ACL, traffic that is not explicitly permitted is dropped.
• Service (Protocol) — Uses a Layer 3 or Layer 4 protocol match condition based on the value of the IP Protocol
field. You can choose one of these options:
◦ All Traffic — Allows all traffic that meets the rule criteria.
◦ Select From List — Choose one of these protocols: IPv6, ICMPv6, TCP, or UDP.
◦ Custom — Enter a standard IANA-assigned protocol ID from 0 to 255. Choose this method to identify a
protocol not listed in the Select From List.
• Source IPv6 Address — Requires the packet's source IP address to match the address defined in the appropriate
fields.
◦ Any— Allows for any IP address.
◦ Single Address — Enter the IP address to apply this criteria.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
69
Access Control
Configure IPv6 ACLs

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
