Cisco WAP125 Administrator's Guide

Step 4
Click Save to add the group to the SNMPv3 Groups list.
To delete a group, check the group in the list and click Delete. To edit a group, check the group in the list and
click Edit.
Note
SNMPv3 Users
Use the SNMP Users page to define users, associate a security level to each user, and configure the security
keys per user.
Each user is mapped to a SNMPv3 group, either from the predefined or user- defined groups, and, optionally,
is configured for authentication and encryption. For authentication, only the SHA type is supported. For
encryption, only the DES and AES128 types are supported. There are no default SNMPv3 users on the WAP
device, and you can add up to eight users.
To add SNMP users follow these steps:
Step 1
Select Management > SNMPv3.
Step 2
Click ✚ to add a new row to the SNMPv3 Users table.
Step 3
Check the box in the new row and configure these parameters:
• User Name — Enter the name that identifies the SNMPv3 user. User names can contain up to 32 alphanumeric
characters.
• Group — Enter the name of group that the user is mapped to. The default groups are RW and RO. You can define
additional groups on the SNMP Groups page.
• Authentication Type — Choose the type of authentication to use on the SNMPv3 requests from the user, from
the following options:
◦ SHA — Requires SHA authentication on SNMP requests from the user.
◦ None — SNMPv3 requests from this user require no authentication.
• Authentication Pass Phrase — If you specify SHA as the authentication type, enter the pass phrase to enable the
SNMP agent to authenticate the requests sent by the user. The pass phrase must be between 8 and 32 characters in
length.
• Encryption Type — Choose the encryption/privacy type applied to the user's SNMP requests from the following
options:
◦ DES — Uses DES encryption on the SNMPv3 requests from the user.
◦ AES128 — Uses AES128 encryption on the SNMPv3 requests from the user.
◦ None—SNMPv3 requests from this user require no privacy.
• Encryption Pass Phrase — If you specify DES or AES128 as the encryption type, enter the pass phrase to use to
encrypt the SNMP requests. The pass phrase must be between 8 and 32 characters in length.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
29
System Configuration
SNMPv3 Users

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
