Cisco WAP125 Administrator's Guide

• Configuration File Name—If you specify the configuration file name, it is retrieved from TFTP Server
during Auto Configuration of AP, in case the boot file name is not received from DHCP server. Absence
of this value indicates config.xml to be used. The file must have an xml extension if specified.
The value is used during the Auto Configuration procedure during next boot-up.
• Wait Interval—If configured, Access Point comes up with the local configuration and makes enabled
services available to the user, after the wait interval. Access point aborts Auto configuration if TFTP
transaction is not initiated within this interval specified.
The value is used during the Auto Configuration procedure during next boot-up.
• Status Log—This field displays reason of Auto Configuration completion or abort.
IPv6 Configuration
Use the IPv6 Setting page to configure the IPv6 address by following these steps:.
Step 1
Select LAN > IPv6 Configuration.
Step 2
Configure the following parameters:
• IPv6 Connection Type — Select one of the following options:
◦ DHCPv6 — The IPv6 address is assigned by a DHCPv6 server.
◦ Static IPv6 — Manually configure the IPv6 address. The IPv6 address should be in a form similar to
xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx (2001:DB8:CAD5:7D91).
• IPv6 Administrative Mode — Check Enable to enable IPv6 administrative mode.
• IPv6 Auto Configuration Administrative Mode — Check Enable to enable the IPv6 automatic address
configuration.
When the IPv6 automatic address configuration is enabled, the WAP device recognizes its IPv6 addresses and
gateway by processing the router advertisements received on the LAN port. The WAP device can have multiple
auto-configured IPv6 addresses.
• Static IPv6 Address — Enter the static IPv6 address. The WAP device can have a static IPv6 address even if
addresses have already been configured automatically.
• Static IPv6 Address Prefix Length — Enter the prefix length of the static address, which is an integer in the range
of 0 to 128. The default is 0.
• Static IPv6 Address Status — Select one of the following options:
◦ Operational — The IP address has been verified as unique and is usable on the LAN interface.
◦ Tentative — The WAP device automatically initiates a duplicate address detection (DAD) process when a
static IP address is assigned. This IPv6 address is tentative as it is being verified on the network and cannot
be used to transmit or receive traffic.
◦ Blank (no value) — No IP address is assigned.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
11
System Configuration
IPv6 Configuration

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
