Cisco WAP125 Administrator's Guide

Use the User Accounts page to configure up to four additional users and change the user password.
Adding a User
Configure the following settings to add a new user:
Step 1
Select System Configuration > User Accounts.
The User Account Table shows the currently configured users. The user cisco is preconfigured in the system and has
Read/Write privileges.
All other users can have Read Only access, but not Read/Write access.
Step 2
Click ✚ to add a new row.
Step 3
Check the box for the new user and enter a name for the new user.
Step 4
Enter the New Password between 0 and 127 characters and then enter the same password in the Confirm New Password
field.
The Password Strength Meter field indicates the password strength as follows:
• Red — The password fails to meet the minimum complexity requirements.
• Orange — The password meets the minimum complexity requirements but the password strength is weak.
• Green — The password is strong.
Step 5
Click Save.
To delete a user, select the user name and click Delete. To edit an existing user, select the user name and click
Edit, then click Save to save all changes made to the configurations.
Note
Changing a User Password
To change a user password:
Step 1
Select System Configuration > User Accounts.
The User Account Table shows the currently configured users. The user cisco is preconfigured in the system to have
Read/Write privileges. The password for the user cisco can be changed.
Step 2
Select the user to configure and click Edit.
Step 3
Enter a New Password between 0 and 127 characters and then enter the same password in the Confirm New Password
field.
The Password Strength Meter indicates the password strength as follows:
• Red — The password fails to meet the minimum complexity requirements.
• Orange — The password meets the minimum complexity requirements but the password strength is weak.
• Green — The password is strong.
Cisco WAP125 Wireless-AC/N Dual Band Desktop Access Point with PoE
22
System Configuration
Adding a User

Cisco WAP125 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Number of users	64 user(s)
Networking standards	IEEE 802.3af, IEEE 802.11ac
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	867 Mbit/s
Security algorithms	WPA, WPA2
Number of SSID supported	8
Supported network protocols	IPv6, NTP, HTTP, HTTPS
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Output current	1 A
Output voltage	12 V
Power plug type	Type C
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Placement	Desk
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407; RSS-210; EN 300.328, EN 301.893; AS/NZS 4268.2003; FCC 15.107 15.109, ICES-003, EN 301.489-1 -17
Product color	White
Recommended usage	Indoor
Cable lock slot type	Kensington
Antenna type	Internal
Antenna gain level (max)	5.63 dBi
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Country of origin	China
Quantity per pack	1 pc(s)
Package depth	188.976 mm
Package width	168.91 mm
Package height	80.01 mm
Package weight	1133.98 g

Weight and Dimensions

Width	123.19 mm
Height	31.75 mm
Weight	303.91 g
